Madenr - Interrupteur sectionneur 2 pôles Ex9BI 40 A
Connectez-vous pour accéder au prix et commander
Spécificités essentielles
calibre/courant nominal assigné (In) - 40 A
fonction de commutation - interrupteur on/off
avec voyant indicateur - Non
profondeur d'encastrement - 79.5 mm
type de tension - AC
Emballage et conditions
1 unité(s)
Produit non retournable
EAN
8592765023872
Réf. Sonepar
03054502387
Réf. Fournisseur
102386
Réf. Commerciale
Madenr
calibre/courant nominal assigné (In)
40 A
fonction de commutation
interrupteur on/off
avec voyant indicateur
Non
profondeur d'encastrement
79.5 mm
type de tension
AC
tension assignée (Ue)
400 V
nombre de pôles
2
résistance de court-circuit (Icw)
1 kA
pouvoir de coupure nominal
1.5 kA
largeur en nombre de modules
2
couleur de la calotte
gris
indice de protection (IP)
IP20
Interrupteur sectionneur 2 pôles Ex9BI 40 A
Les Atouts de l'article:
Isolators Ex9BI can be used as a main switch in wide variety of applications. These switches are tested accordingto IEC / EN 60947-3 standards and fulfill also requirements for isolation function.Utilization category AC-22A ensures possibility of switching mixed resistive and inductive loads with low overloadswith cos j = 0.65. Subcategory A allows frequent operation.Isolators of line Ex9BI are produced in modular design with width one module unit per pole. Can be connectedvia standard busbars of both fork as well as pin type of connection.Ex9BI Isolators can be also combined with wide range of accessories including auxiliary contacts, shunt tripreleases, undervoltage and overvoltage releases. It is possible to create diversed combination of accessories.
