![Madenr - Contacteur modulaire manuel EX9CH32M : 2 NF, 24 VAC, 32 A](https://fra-connect.mo.cloudinary.net/PRODUCT/IMAGE/3054/Ex9CH32M2P.jpg?ts=1704848866525)
Madenr - Contacteur modulaire manuel EX9CH32M : 2 NF, 24 VAC, 32 A
Connectez-vous pour accéder au prix et commander
Spécificités essentielles
type de tension de fonctionnement - AC
courant de fonctionnement nominal - 32 A
tension d'actionnement assignée - 24...24 V
produits auxiliaires associables - Non
indice de protection (IP) - IP20
Emballage et conditions
1 unité(s)
Produit non retournable
EAN
8592765117014
Réf. Sonepar
03054511701
Réf. Fournisseur
111701
Réf. Commerciale
Madenr
type de tension de fonctionnement
AC
courant de fonctionnement nominal
32 A
tension d'actionnement assignée
24...24 V
produits auxiliaires associables
Non
indice de protection (IP)
IP20
profondeur d'encastrement
73 mm
tension de fonctionnement normale
250...250 V
catégorie d'utilisation
1
curseur pour commutation manuelle
Oui
type de tension d'actionnement
AC
Contacteur modulaire manuel EX9CH32M : 2 NF, 24 VAC, 32 A
Les Atouts de l'article:
Installation contactors with manual operation Ex9CHM are suitable for household and building modular distributionboards. It is used as remote or manual switch for circuit control under AC-7b and AC-7a applicationcategory (e.g. mixers, blenders, fans, central vacuum).The contactor shall not be used for breaking short-circuit current, therefore it should be used with a propershort-circuit protection device.The contactor has 4 selectable positions:• O - permanently OFF• AUTO - switched while the supply voltage is provided to the coil• I - manually swicthed , automatically returns to “AUTO“ position after the supply voltage ends• I+P - permanently ON
